Engine Type: Single-Cylinder
Displacement: 34.6 cu. in. (567 cc)
Bore and Stroke: Bore: 3.9 in. (99 mm); Stroke: 2.94 in. (74.6 mm)
Cooling: Liquid
Compression Ratio: 10:1
Fuel System: Gas
Front Suspension: McPherson Strut
Front Brakes: Hydraulic Disc
Front Tire: Carlstar 489: 25 x 8-12
Rear Suspension: Independent Double A-Arm
Rear Brakes: Hydraulic Disc
Rear Tire: Carlstar 489: 25 x 10-12
Dry Weight: 1155 lb. (524 kg.)
Wheelbase: 73.2 in. (1860 mm)
Front Travel: 9 in. (229 mm)
Rear Travel: 10 in. (254 mm)
Ground Clearance: 10 in. (254 mm)
Fuel Capacity: 9.5 gal. (35.9 L)
Box Capacity: 500 lbs. (226.8 kg.)
Towing Capacity: 1500 lb. (680.4 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
